ElephMax Vacuum Automatic Press System for High-Efficiency Laminating & Forming
The ElephMax vacuum automatic press machine is an industrial vacuum membrane pressing solution used to bond flexible decorative materials ( such as PVC films, natural wood veneers, and heat transfer foils) onto flat, curved, and contoured wooden surfaces. With the vacuum pressure reaching ≥ -0.095 MPa, the ElephMax vacuum automatic press machine provides uniform pressure distribution for smooth, bubble-free finishes, even when you are processing intricate shapes, curves, and embossed patterns up to 60 mm thick. The advanced infrared heating system can reach up to 185°C, while smart microcomputer temperature control helps maintain consistent heating throughout the whole pressing process. Thanks to the controlled combination of heat and vacuum pressure, it is easier to achieve a uniform finish during your processing, whilst minimising issues such as uneven adhesion, film scorching and edge curling.
The ElephMax vacuum press is suitable for the production of bespoke kitchen units, cabinet doors, decorative doors, decorative wall panels, panel furniture and other customised wood products. You can flexibly configure the worktable, clamping system, feeding mechanism and control components to create a solution that is perfectly tailored to your needs.
Make Money using Vacuum Pressing Machine
A6L features dual working stations, infrared heating, rapid vacuum pumping, and compatibility with PVC, veneer, and transfer films.
Vacuum Pressure Machine’s Feature
High vacuum pressure with vacuum pressure reaching ≥ −0.095 MPa, it keeps films and veneers tightly pressed against the workpiece during every forming process.
With even heat distribution across the working area, it helps prevent uneven softening and improves the consistency of film and veneer bonding during processing.
Curved surface forming for curved, recessed, raised, and irregular workpieces, allowing you to process shaped furniture doors, decorative panels, and other 3D components.
A well-sealed vacuum chamber maintains stable negative pressure during the pressing cycle for reliable forming results.
PLC-based control manages key pressing steps such as heating, vacuuming, pressure holding, and cooling for your repeatable production.
A user-friendly control interface makes it easier to set and monitor heating, vacuum, and pressing parameters during production.
Available with different working sizes and configurations to match production volume, workpiece dimensions, and material requirements.
Built for continuous industrial use, with robust machine construction and options such as vacuum pumps, viewing windows, and shuttle-style configurations.
Faster Cycles, Higher Daily Output
Turn every pressing cycle into more productive output. The 3000 × 1300 mm + 3000 × 1300 mm working configuration provides a large processing area for handling multiple workpieces, while the automatic vacuum pressing process reduces manual intervention between cycles. With a 25–32 kW total installed power and only 7–9 kW actual power consumption, the machine is built to support efficient production without adding unnecessary operating costs. Its total machine weight of approximately 2 tons and controlled heating up to 185°C provide a reliable foundation for demanding furniture and industrial production.
One Machine, More Production Possibilities
Take on more materials and product types without limiting your production to standard flat panels. Vacuum pressing can be used for PVC films, wood veneers, and decorative materials, while its ability to handle workpieces up to 60 mm in processing height makes it suitable for furniture doors, cabinet panels, shaped components, and other three-dimensional applications. Expand your product range with one flexible pressing solution.
Say Goodbye to ‘Manual Veneer Application’ & ‘Bubbling at the Edges’
Get smooth, clean finishes across flat, curved, recessed, and irregular workpieces. With vacuum pressure reaching ≥ −0.095 MPa, the machine pulls films and veneers tightly against the entire surface, helping minimize air bubbles, wrinkles, edge lifting, and uneven adhesion. From cabinet doors and furniture panels to 3D decorative components, achieve a more consistent finish with less rework and fewer quality issues.
Why Buy Directly From ElephMax Factory?
- 16+ Years of Manufacturing Expertise: Dedicated to premium CNC & vacuum laminating solutions.
- 75,000 m² Smart Manufacturing Base: Integrated machining, precision assembly, and strict quality inspection ensure fast global delivery.
- Trusted by 9,000+ Customers Worldwide: Exported to over 180 countries across the furniture and woodworking industries.
- Rigorous Quality Control: Every automatic vacuum press machine undergoes 72-hour continuous testing before shipment to guarantee stable, long-term performance.
- 500+ Engineering Support Team: Complete pre-sales consultation, custom workflow design, and 24/7 responsive technical support.
- 120+ Patents & Global Certifications: Fully ISO9001, BV, and CE certified, meeting strict international safety standards.
Industries We Serve
Improve the efficiency of furniture and cabinet production with consistent vacuum pressure and uniform heating. The machine is suitable for PVC film wrapping, wood veneer pressing, and forming on cabinet doors, furniture panels, curved surfaces, and irregular-shaped components.
Handle a wide range of door styles, including flat doors, raised-panel doors, grooved doors, molded doors, and curved doors. The vacuum pressing process helps PVC films, veneers, and decorative foils conform closely to different door profiles, supporting consistent clean finishes across various designs.
Support flexible production of customized furniture, wall panels, and special-shaped wood products. The vacuum pressing process adapts to different workpiece shapes and materials, making it suitable for both standard panels and more complex decorative designs.
Apply vacuum pressure and controlled heating for selected composite and industrial materials that require uniform forming or bonding. It can be used for automotive interior components, composite panels, and other shaped parts where consistent pressure and surface quality are important.
More About Our Company
- Certifications
- Vacuum Press Machine Video
- Specifications
Every vacuum press machine is built in full compliance with international manufacturing standards and backed by authoritative patents and certifications . Tested with advanced inspection equipment, our machines guarantee long-lasting precision and reliability for all your machining needs.
| Parameter | Automatic Vacuum Press Machine |
| Overall Size | 3000 × 1300 mm + 3000 × 1300 mm |
| Maximum Processing Height | 60 mm |
| Fixed Working Pressure | ≥ −0.095 MPa |
| Total Power | 25–32 kW |
| Actual Power Consumption | 7–9 kW |
| Total Weight | 2 T |
| Maximum Temperature | 185 °C |
Testimonials
We switched from manual veneering to the ElephMax double-station vacuum press. I reduced my manual labor and the cut rework caused by bubbling reduced greatly.
Luke. | Architectural Interior Design | AustriaWe really like the twin-station setup on our ElephMax vacuum press. While one table is pressing, we can unload and prep the other, which has made our cabinet door production much faster.
Julian P. | Commercial Millwork & Joinery | CanadaThanks to ElephMax, we’ve been able to keep production running smoothly across thousands of PVC-wrapped panels.
Henrik B. | Hotel & Office Furniture Supply | Poland
To select the correct machine, you should match your workpiece material, coating type, and thickness against key machine specifications:
- Workpiece Geometry & Height: Ensure the machine’s maximum processing height (e.g., 60mm) accommodates your 3D parts or deep-embossed profiles.
- Material Temperature: Verify that the heating system matches your laminating film or veneer requirements (e.g., up to 185 °C for PVC and wood veneers).
- Bonding Method: Choose a machine compatible with hot-melt adhesives or thermoformable films based on your material’s thermal properties.
| Feature | Membrane Vacuum Press | Membraneless Vacuum Press |
| How It Works | Uses a flexible membrane to press materials evenly. | Uses the heated film itself to create the vacuum seal. |
| Main Materials | Wood veneer, laminates, decorative sheets. | PVC film, decorative film, transfer foil. |
| Best For | Veneer, laminate, and various surface materials. | Cabinet doors, furniture panels, and 3D film wrapping. |
| Pressure | Membrane helps distribute atmospheric pressure evenly over the workpiece, | Vacuum pulls the film directly onto the workpiece. |
| Key Advantage | More material flexibility. | Simple and efficient for film wrapping. |
| Typical Use | Furniture and architectural panels. | PVC-wrapped doors and shaped furniture panels. |
The machine achieves seamless, bubble-free finishes through a two-step process:
- High Vacuum Pressure: A powerful vacuum pump creates negative pressure up to −0.095 MPa, evacuating all air trapped between the decorative film and the substrate.
- Uniform Pressure Distribution: Atmospheric pressure exerts equal force across every surface, curve, and recessed groove simultaneously, pressing the material firmly into the adhesive layer while eliminating localized air pockets.
Our vacuum press machines can handle workpieces up to 60 mm thick, with working table sizes available up to 3000 × 1300 mm per station. Custom sizes are also available
- Remote Training & Guidance: Comprehensive video tutorials, operational manuals, and 24/7 online technical support with English-speaking engineers via video call or messaging.
- On-Site Installation: Field engineers can be dispatched directly to your facility for on-site machine setup, calibration, and hands-on operator training upon request.
- Lifetime Support: Continuous access to remote troubleshooting, software updates, and fast-ship replacement spare parts.
